IP55轴流风机_苏州平云机电科技有限公司

型号	额定电压	功率	转速	风量	风压	风机类型
PA3N200B24-RN0	24VDC	52.8 W	3000 RPM	1000 m3/H	280 Pa	DC
PA3N200B24-RZ0	24VDC	52.8 W	3000 RPM	1000 m3/H	280 Pa	DC
PA3N200B2E-RN0	230 VAC	58 W	3000 RPM	1150 M³/H	310 Pa	EC
PA3N200B2E-RZ0	230 VAC	58 W	3000 RPM	1150 M³/H	310 Pa	EC
PA3N200B2E-SN0	230 VAC	115 W	4100 RPM	1650 m3/H	200 Pa	EC
PA3N200B2E-SZ0	230 VAC	115 W	4100 RPM	1650 m3/H	200 Pa	EC
PA3N200B48-RN0	48VDC	52.8 W	3000 RPM	1000 m3/H	280 Pa	DC
PA3N200B48-RZ0	48VDC	52.8 W	3000 RPM	1000 m3/H	280 Pa	DC
PA3N250B24-RN0	24VDC	67.2 W	2500 RPM	1700 m3/H	220 Pa	DC
PA3N250B24-RZ0	24VDC	67.2 W	2500 RPM	1700 m3/H	220 Pa	DC
PA3N250B2E-RN0	230 VAC	85 W	4100 RPM	1650 m3/H	200 Pa	EC
PA3N250B2E-RZ0	230 VAC	85 W	2600 RPM	1700 m3/H	210 Pa	EC
PA3N250B2E-SN0	230 VAC	120 W	3000 RPM	1900 m3/H	200 Pa	EC
PA3N250B2E-SZ0	230 VAC	120 W	3000 RPM	1900 m3/H	200 Pa	EC
PA3N250B48-RN0	48VDC	67.2 W	2500 RPM	1700 m3/H	220 Pa	DC
PA3N250B48-RZ0	48VDC	67.2 W	2500 RPM	1700 m3/H	220 Pa	DC
PG3N300B2E-MN0	230 VAC	220 W	2200 RPM	2800 m3/H	230 Pa	EC
PG3N300B2E-MZ0	230 VAC	220 W	2200 RPM	2800 m3/H	230 Pa	EC
PG3N300B2E-TN0	230 VAC	150 W	1920 RPM	2400 m3/H	160 Pa	EC
PG3N350B2E-MZ0	230 VAC	200 W	1580 RPM	3500 m3/H	230 Pa	EC
PG3N350B2E-ZN5	230 VAC	700 W	2500 RPM	4700 m3/H	500 Pa	EC
PG3N400B2E-MN0	230 VAC	170 W	1200 RPM	4000 m3/H	110 Pa	EC
PG3N400B2E-MZ0	230 VAC	170 W	1200 RPM	4000 m3/H	110 Pa	EC
PG3N400B2E-ZN5	230 VAC	700 W	1800 RPM	5900 m3/H	300 Pa	EC
PG3N400B2E-ZW5	230 VAC	700 W	1800 RPM	5900 m3/H	300 Pa	EC
PG3N450B2E-ZN5	230 VAC	380 W	1400 RPM	7400 m3/H	270 Pa	EC
PG3N450B2E-ZW5	230 VAC	380 W	1400 RPM	7400 m3/H	270 Pa	EC
PG3N500B2E-ZN5	230 VAC	700 W	1550 RPM	8700 m3/H	250 Pa	EC
PG3N500B2E-ZW5	230 VAC	700 W	1550 RPM	8700 m3/H	250 Pa	EC
PW3N300B2E-TZ0	230 VAC	150 W	1920 RPM	2400 m3/H	150 Pa	EC

咨询

IP55轴流风机

IP55轴流风机

IP55轴流风机

IP55轴流风机

IP55轴流风机

Axial Fan Technical Features Overview

轴流风机技术特性概述

参数汇总表
