IP55后向离心风机_苏州平云机电科技有限公司

型号	额定电压	功率	转速	风量	风压	风机类型
PB3N133B24-FZ5	24VDC	33 W	4500 RPM	270 m3/H	450 Pa	DC
PB3N133B24-RB0	24VDC	50 W	5000 RPM	420 m3/H	750 Pa	DC
PB3N133B2E-FZ0	230 VAC	30 W	4250 RPM	281 m3/H	459 Pa	EC
PB3N133B2E-FZ5	230 VAC	34 W	4450 RPM	280 m3/H	500 Pa	EC
PB3N133B2E-RB2	230 VAC	43 W	4400 RPM	415 m3/H	450 Pa	EC
PB3N133B48-FZ5	48VDC	33 W	4500 RPM	270 m3/H	450 Pa	DC
PB3N133B48-RB0	48VDC	50 W	5000 RPM	420 m3/H	750 Pa	DC
PB3N175B24-RZ0	24VDC	85 W	4300 RPM	750 m3/H	650 Pa	DC
PB3N175B2E-FZ5	230 VAC	40 W	3200 RPM	535 m3/H	451 Pa	EC
PB3N175B2E-RZ0	230 VAC	72 W	4050 RPM	710 m3/H	550 Pa	EC
PB3N175B2E-SZ0	230 VAC	110 W	4600 RPM	700 m3/H	800 Pa	EC
PB3N175B48-RZ0	48VDC	85 W	4300 RPM	750 m3/H	650 Pa	DC
PB3N190B24-RZ0	24VDC	85 W	3500 RPM	710 m3/H	840Pa	DC
PB3N190B24-TZ0	24VDC	120 W	4050 RPM	820 m3/H	780 Pa	DC
PB3N190B24-TZ1	24VDC	153.6 W	4400 RPM	880 m3/H	950 Pa	DC
PB3N190B2E-RZ0	230 VAC	52 W	2940 RPM	540 m3/H	450 Pa	EC
PB3N190B2E-RZ1	230 VAC	70 W	3300 RPM	685 m3/H	530 Pa	EC
PB3N190B2E-RZ2	230 VAC	110 W	3700 RPM	800 m3/H	790 Pa	EC
PB3N190B2E-SZ0	230 VAC	110 W	3800 RPM	810 m3/H	850 Pa	EC
PB3N190B2E-TZ0	230 VAC	170 W	4550 RPM	945 m3/H	1000 Pa	EC
PB3N190B48-RZ0	48VDC	85 W	3500 RPM	710 m3/H	840Pa	DC
PB3N190B48-TZ0	48VDC	120 W	4050 RPM	820 m3/H	780 Pa	DC
PB3N190B48-TZ1	48VDC	153.6 W	4400 RPM	880 m3/H	950 Pa	DC
PB3N220B24-RZ0	24VDC	85 W	2600 RPM	1010 m3/H	700 Pa	DC
PB3N220B24-TZ0	24VDC	182.4 W	3500 RPM	1165 m3/H	950 Pa	DC
PB3N220B2E-RZ0	230 VAC	85 W	2670 RPM	960 m3/H	760 Pa	EC
PB3N220B2E-SZ0	230 VAC	110 W	3100 RPM	1000 m3/H	580 Pa	EC
PB3N220B2E-TZ0	230 VAC	170 W	3500 RPM	1255 m3/H	1010 Pa	EC
PB3N220B48-RZ0	48VDC	85 W	2600 RPM	1010 m3/H	700 Pa	DC
PB3N220B48-TZ0	48VDC	182.4 W	3500 RPM	1165 m3/H	950 Pa	DC
PB3N225B24-RG0	24VDC	96 W	2400 RPM	1100 m3/H	690 Pa	DC
PB3N225B24-TG0	24VDC	168 W	3000 RPM	1280 m3/H	960 Pa	DC
PB3N225B2E-MG0	230 VAC	220 W	3500 RPM	1350 m3/H	900 Pa	EC
PB3N225B2E-RG0	230 VAC	85 W	2300 RPM	975 m3/H	620 Pa	EC
PB3N225B2E-RG1	230 VAC	100 W	2450 RPM	1100 m3/H	720 Pa	EC
PB3N225B2E-SG0	230 VAC	110 W	2600 RPM	1150 m3/H	750 Pa	EC
PB3N225B2E-TG0	230 VAC	170 W	3200 RPM	1300 m3/H	1000 Pa	EC
PB3N225B48-RG0	48VDC	96 W	2400 RPM	1100 m3/H	690 Pa	DC
PB3N225B48-TG0	48VDC	168 W	3000 RPM	1280 m3/H	960 Pa	DC
PB3N250B24-RZ0	24VDC	86.4 W	2000 RPM	1170 m3/H	630 Pa	DC
PB3N250B24-TZ0	24VDC	153.6 W	2700 RPM	1350 m3/H	900 Pa	DC
PB3N250B2E-MZ0	230 VAC	220 W	3100 RPM	1600 m3/H	750 Pa	EC
PB3N250B2E-RZ0	230 VAC	85 W	2100 RPM	1150 m3/H	610 Pa	EC
PB3N250B2E-SZ0	230 VAC	115 W	2350 RPM	1250 m3/H	600 Pa	EC
PB3N250B2E-TZ0	230 VAC	170 W	2750 RPM	1500 m3/H	915 Pa	EC
PB3N250B2E-YZ5	230 VAC	550 W	3600 RPM	2750 m3/H	1330 Pa	EC
PB3N250B48-RZ0	48VDC	86.4 W	2000 RPM	1170 m3/H	630 Pa	DC
PB3N250B48-TZ0	48VDC	153.6 W	2700 RPM	1350 m3/H	900 Pa	DC
PB3N250B4E-YZ5	380VAC	750 W	4100 RPM	3000 m3/H	1400 Pa	EC
PB3N280B2E-MZ0	230VAC	210 W	2600 RPM	2000 m3/H	800 Pa	EC
PB3N280B2E-YZ5	230VAC	700 W	3300 RPM	3720 m3/H	1600 Pa	EC
PB3N280B4E-YZ5	380VAC	800 W	3400 RPM	3700 m3/H	1180 Pa	EC
PB3N310B2E-MZ0	230 VAC	220 W	2100 RPM	2500 m3/H	650 Pa	EC
PB3N310B2E-YZ5	230 VAC	700 W	2850 RPM	4850 m3/H	1590 Pa	EC
PB3N310B4E-YZ5	380VAC	1100 W	3000 RPM	4500 m3/H	1600 Pa	EC
PB3N355B2E-ZW5	230 VAC	700 W	2150 RPM	5400 m3/H	1080 Pa	EC
PB3N355B4E-ZW5	380VAC	1100 W	2500 RPM	6700 m3/H	1150 Pa	EC
PB3N400B2E-ZW5	230 VAC	700 W	1750 RPM	6700 m3/H	1000 Pa	EC
PB3N400B4E-ZW5	380VAC	1300 W	2000 RPM	7400 m3/H	1000 Pa	EC
PB3N450B2E-ZW5	230 VAC	700 W	1550 RPM	6900 m3/H	650 Pa	EC
PB3N450B4E-ZW5	380VAC	1000 W	1800 RPM	7200 m3/H	700 Pa	EC

IP55后向离心风机

IP55后向离心风机

IP55后向离心风机

IP55后向离心风机

IP55后向离心风机

IP55后向离心风机

后向离心风机技术特性概述

参数汇总表
